Mag Encoder lC
The MEMSlC mag encoder chip is a MEMs sensor based on anisotropic magnetoresistance (AMR technology, Compared with the traditional Hallmag encodesensor, AMR Mag Encoder is more .accurat,lower noise and lovtemperature drift, The sensor implements ASlC signal processing chip to output highprecision absolute angular position, can replace some optical encoder application scenarios
Technical Advantages
Multiple power supply voltages
VDD：3-5.5V
High-accuracy
INL Angleaccuracy<±0.07°；Can replace someoptical encoder applications
Multiple Interfaces
21-bit SPI up to10Mhz；12-bit PWM；ABZ-16；384 PPR；UVW
Anti- interference
AMR works in thesaturation zone and is resistant to horizontal magneticfield interference
Circle counting
Circle counting function max .65536
